Motorized cantilever decoiler KR-2,0 NC

Price on request

Последний раз этот товар купили вчера

Прямо сейчас этот товар просматривает 1 человек

array(0) {
}

Description
Advantages
Specifications
Description

Motorized cantilever decoiler KR-2,0 NC is designed for uncoiling a band up to 350 mm wide and a coil weight up to 2,000 kg.

It is applied in combination with stamping, shaping or other production lines. The decoiler is equipped with an electric drive and a closed-loop control system for monitoring of the operation speed. A sensor is used to analyze the loop sagging level, depending on it the drive speed is controlled smoothly and steplessly. The operation is free of jerks and overloads, which allowed decreased the drive power and, respectively, the power consumption.

A distinctive feature of the roll decoiler is fully automated self alighment of the coil. When a button on the control panel is pressed, 3 suport bars move synchronically. The presence of restrainers allows uncoiling narrow band. To avoid impact loads, 2 protection options are stipulated in the design: mechanical - friction type overload clutch with frictional torque adjustment, and electrical - frequency converter smoothly controls electric motor speed.


Advantages
  • open side design for easy roll installation;
  • self centering coil;
  • automatic, manual, reverse
  • drive speed is controlled smoothly and steplessly;
  • overload protection (mechanical and electrical).
Specifications
Coil width, mm 10 - 350
Inner Ø of coil, mm 380 - 630
Maximum load, kg up to 2000
Operating mode Automatic, manual, reverse
Mandrel expansion elecrical
Operating speed, r/min (controlled by automatics) up to 10
Drive power, kW 0,75
Supply voltage, V 220
Dimensions, LхWхH, mm 920х1000х1130
Weight, kg 160
